Billion BiPAC 5200N Specifications

Features & Specifications
ADSL Compliance
• Compliant with ADSL Standard
- Full-rate ANSI T1.413 Issue 2
- G.dmt (ITU G.992.1)
- G.lite (ITU G.992.2)
- G.hs (ITU G.994.1)
- ADSL over ISDN/U-R2
• Compliant with ADSL2 Standard
- G.dmt.bis (ITU G.992.3)
- ADSL2 Annex M (ITU G.992.3 Annex M)
(available for BiPAC 5200NA model only)
• Compliant with ADSL2+ Standard
- G.dmt.bis plus (ITU G.992.5)
- ADSL2+ Annex M (ITU G.992.5 Annex M)
(available for BiPAC 5200NA model only)
Network Protocols and Features
• NAT, static routing and RIP-1/2
• NAT supports PAT and multimedia applications
• Multi-to-multi NAT
• Transparent Bridging
• Dynamic Domain Name System (DDNS)
• Virtual Server and DMZ
• SNTP, DNS relay and IGMP proxy
Firewall & Virtual Private
Network (VPN)
• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• Prevents DoS attacks including Land Attack,
Ping of Death, etc.
• Anti probe function
• Packet filtering
• URL Filtering
• Password protection for system management
• VPN pass-through
Quality of Service Control
• Supports the DiffServ approach
• Traffic prioritization based-on IP protocol,
port number and address
Operating Environment
• Operating temperature: 0 - 40
º
C
• Storage temperature: -20 - 70
º
C
• Humidity: 20 - 95% non-condensing
Wireless LAN
• Compliant with IEEE 802.11n, 802.11g and
802.11b standards
• 2.4 GHz – 2.484 GHz frequency range
• Auto channel select
• Up to 300Mbps wireless operation rate
• WPS (Wi-Fi Protected Setup) for easy setup
(* future release)
• 64/128 bits WEP supported for encryption
• Wireless Security with WPA-PSK/
WPA2-PSK support
• WDS repeater function support (* future release)
ATM and PPP Protocols
• ATM Adaptation Layer Type 5 (AAL5)
• Multiple Protocol over AAL5
(RFC 2684, formerly RFC 1483)
• Bridged or routed Ethernet encapsulation
• VC and LLC based multiplexing
• PPP over Ethernet (PPPoE)
• PPP over ATM (RFC 2364)
• OAM F4/F5
• ATM QoS: UBR, CBR, VBR-rt, VBR-nrt
Management
• Web-based configuration
• Firmware upgrades and configuration data
upload/download via web-based interface
• SNMP v1/v2 MIB supported
• Supports DHCP server/client/relay
Hardware Specifications
Physical Interface
• WLAN: 3 external antennas
• DSL: ADSL port
• Ethernet: 4-port 10/100M
auto-crossover (MDI/MDI-X) switch
• Factory default reset button
• WPS button
• Power jack
Physical Specifications
• Dimensions: 7.28" x 4.86" x 1.42"
(185mm x 123.5mm x 36mm)
Power Requirements
• Input: 12V DC, 1A
Models & Supported
Standards
• BiPAC 5200NA: Supports Annex A
and Annex M
• BiPAC 5200NU: Supports U-R2 and
Annex B
• Annex A and Annex M: ADSL
over POTS
• Annex B and U-R2: ADSL over ISDN
Notes:
1. The router may require firmware modification for certain ADSL2/2+/Annex M DSLAMs.
2. Actual throughput and performance depends on the environment. Normally, the wireless speed is faster if you are closer to the router. The farther from the router you are, the more
wireless range, and slower speed, you get.
3. Specifications in this datasheet are subject to change without prior notice.
V.031308
8F, No.192, Sec.2, Chung Hsing Road,
Hsin Tien City, Taipei County, 23146 Taiwan
www .billion.com
Billion Electric Co., Ltd.
TEL : +886-2-2914-5665
FAX : +866-2-2918-6731, +886-2-2918-2895
E-mail : sales@billion.com
Internet
Switching
HUB
ADSL2+
W
ireless
Security
Firewall
BiPAC 5200N

Billion BiPAC 5200N Specifications

Operating Environment

operating temperature	0 - 40 ºC
storage temperature	-20 - 70 ºC
humidity	20 - 95% non-condensing

Physical Specifications

dimensions	185mm x 123.5mm x 36mm
wireless operation rate	Up to 300Mbps
frequency range	2.4 GHz – 2.484 GHz

Power

input voltage	12V DC
input current	1A
