6
1. PRODUCT OVERVIEW
B-260-HDMI-CTRL is an HDMI In-line Controller, with resolutions up to 4K@60Hz (chroma
sub-sampling 4:4:4 8-bit only) and HDCP 2.2.
Its digital or analog audio outputs allow audio to be de-embedded from HDMI input and sent
to audio distribution system, such as Amplifie. Its rotary EDID switch has 15 EDID presets and
can help negotiate the HDMI handshake in certain situations, such as an old HDMI display with
DDC channel invalid, or DVI display with audio amplified requirement
By auto-detecting input signal status, it could automatically trigger CEC commands to turn on
or off CEC-enabled TV, pre-loaded RS232 commands to power on or standby projector, and
relay control to turn on or off projection screen.
2. KEY FEATURES
• Supports video resolutions up to 4K@60Hz 4:4:4 8-bit and HDCP 2.2.
• HDMI audio de-embedded out with Digital Coaxial and Analog Stereo.
• Rotary switch for EDID Management with 15 EDID presets.
• Built-in CEC controller from HDMI out.
• Built-in RS232 controller, to pre-load and store RS232 command of display device.
3. KEY BENEFITS
• Automatic CEC/RS232 commands to power on/standby display device by detecting input
signal status.
• Built-in RELAY control to automatically turn on/off projector screen by detecting input
signal status.
• Automatic input cable equalization and signal regeneration compensation.
4. PACKAGE CONTENT
• 1 x B-260-HDMI-CTRL
• 1 x DC 12V Power Adapter with US Pins
• 3 x Phoenix Male Connectors (3.5 mm, 3 Pins)
• 2 x Mounting Brackets (with Screws)
• 2 x Drywall Screws
• 4 x Rubber Feet
• 2 x Power Cord Labels
• 1 x Installation Manual
