B-200-1CAT-HDIR Installation and Users Manual
pg.14
www.snapav.com Support: 866.838.5052
Technical
Transmitter Receiver
HDMI Compliance HDMI 3D
HDCP Compliance Yes
Video Bandwidth 6.75Gbps
Video Support 480i / 480p / 720p / 1080i / 1080p60
HDMI over UTP
Transmission
Resolution Cat5e Cat6e
1080i / 720p 24-bit color
Full HD 1080P 24-bit color
Full HD 1080P 36-bit deep color
230ft
130ft
65ft
200ft
165ft
65ft
Signal Equalization 8-level digital control at RX
Input TMDS Signal 1.2 Volts (peak-to-peak)
Input DDC Signal 5 Volts (peak-to-peak, TTL)
ESD Protection (1) Human body model — ±15kV (air-gap discharge) & ±8kV
(contact discharge) (2) Core chipset — ±8kV
IR Signal (Bi-directional) Carrier frequency: 20-60kHz
Connections
HD Link 1x RJ45 1x RJ45
HDMI 1x HDMI Type A
(19-pin female)
1x HDMI Type A
(19-pin female)
IR Receiver (In) 1x 3.5mm Mono 1x 3.5mm Stereo
IR Flasher (Out) 1x 3.5mm Mono 1x 3.5mm Mono
Power Latch-Locking Latch-Locking
Controls
Rotary Control Switch EDID Mode Distance Signal level
Mechanical
Housing Metal Enclosure
Dimensions 2.9” x 3.5” x 1”
Weight 1.1 lbs
Power Supply 5V DC 4A
Power Consumption 3 Watt (max)
Operation Temperature 32~104°F
Storage Temperature -4~140°F
Relative Humidity 20~90% RH (no condensation)
7. SPECIFICATIONS
