IF THE SYSTEM IS NOT USED FOR AN EXTENDED PERIOD IT IS RECOMMENDED TO BE FILLED
WITH A LIGHT OIL AFTER CLEANING.
1 - INSERT SUCTION SYSTEM (11) & RETURN HOSE (14) (IF FITTED) INTO A CONTAINER WITH THE FLUID TO
BE SPRAYED
2 - CLOSE VALVE (2) AND SET REGULATORS (3) AND (12) TO ZERO (WIND ANTICLOCKWISE), OPEN VALVE (5)
IF FITTED.
3 - REMOVE SPRAY TIP FROM THE GUN FOR RETURNING FLUID INTO THE CONTAINER.
4 - CONNECT AIR SUPPLY.
a) IF (5) IS FITTED
5a - OPEN VALVE (2), INCREASE REGULATOR PRESSURE (3) UNTIL PUMP STARTS TO OPERATE.
6a - WHEN FLUID FLOWS THROUGH HOSE (14) WITHOUT AERATION, CLOSE VALVE (5).
7a - OPEN SPRAY GUN TRIGGER UNTIL FLUID FLOWS INTO CONTAINER WITHOUT AIR, THEN RELEASE
TRIGGER.
b) IF (5) IS NOT FITTED.
5b - TRIGGER THE SPRAY GUN AND HOLD OVER CONTAINER, INCREASE REGULATOR PRESSURE (3) UNTIL
PUMP STARTS TO OPERATE.
6b - KEEP TRIGGER OPEN UNTIL FLUID FLOWS INTO CONTAINER WITHOUT AERATION, THEN RELEASE
TRIGGER.
8 - REDUCE REGULATOR PRESSURE (3) TO ZERO.
9 - APPLY SPRAY GUN SAFETY LOCK WHILE SPRAY TIP IS FITTED.
10 - INCREASE REGULATOR PRESSURE(3) UNTIL DESIRED ATOMISATION IS ACHIEVED FROM SPRAY GUN.
11 - INCREASE REGULATOR PRESSURE (12) TO ACHIEVE DESIRED SPRAY FAN.
1 - REDUCE REGULATOR PRESSURE (3) AND (12) TO ZERO.
2 - TRIGGER GUN TO REDUCE SYSTEM PRESSURE.
3 - OPEN VALVE (5) SLOWLY IF FITTED.
4 - APPLY SPRAY GUN SAFETY LOCK WHILE SPRAY TIP IS REMOVED
5 - TRIGGER GUN CAREFULLY INTO CONTAINER AND ENSURE FLUID SYSTEM IS DE-PRESSURISED.
6 - CLOSE VALVE(2) AND REMOVE AIR SUPPLY.
7 - APPLY SPRAY GUN SAFETY LOCK.
8 - CLEAN AS INSTRUCTED AND SOAK/CLEAN SPRAYGUN FLUID NOZZLE.
