10 - PART LIST - ARTICULATOR 4000-S
01 UM 1 FRAM1069 LOWER FRAME 4000-S
02 PC 2 FCAN0755 MAGNETIC FITTING
03 UM 2 FECD0049 CONDYLE ELEMENT
04 UM 4 CORI1170 STABILIZING ELASTIC BAND (O´RING)
05 UM 2 CIMA1118 RAIL MOUNTING PLATE MAGNET
06 UM 4 FPIG0076 MOUNTING PLATE GUIDE PIN
07 UM 2 CPIE1524 AFFIXING BLOCK PIN
08 UM 1 SALH0075 BENNETT ANGLE ADJUSTING DEVICE (RIGHT)
09 UM 2 FPIG0062 FACE BOW´S GUIDE PIN
10 UM 1 FCDL1066 CONDYLAR GUIDE (RIGHT)
11 PC 1 FPOS0759 POSITION INDICATOR OF BENNETT ANGLE ADJUSTING DEVICE (RIGHT)
12 UN 2 SCRE0099 SCREW TO FIX THE BENNETT ANGLE ADJUST. DEVICE
13 UN 1 FBCH0059 CONDYLAR BUSH (RIGHT)
14 UN 1 FFUS0042 MICROMETRIC EXPANDING SPINDLE
15 UN 1 FRLD0061 PULLEY
16 UN 2 SCRE0008 CONDILAR GUIDE WING SCREW
17 UN 2 FFIX0057 CONDYLAR GUIDE FIXER
18 UN 1 SCRE0010 MOUNTING PLATE SCREW (UPPER)
19 UN 1 FBCH0060 CONDYLAR BUSH (LEFT)
20 PC 1 FPOS0758 POSITION INDICATOR OF BENNETT ANGLE ADJUSTING DEVICE (LEFT)
21 UN 1 FCDL1067 CONDYLAR GUIDE (LEFT)
22 UN 1 SALH0074 BENNETT ANGLE ADJUSTING DEVICE (LEFT)
23 UN 1 SCRE0011 INCISAL PIN SCREW
24 UN 1 FRAM0056 UPPER FRAME 4000-S
25 UN 4 SPLA0079 RAIL MOUNTING PLATE
26 UN 1 FPIN0053 INCISAL PIN
27 UN 1 CMES1537 INCISAL TABLE STANDARD (POLYCARBONATE)
28 UN 1 FHST0058 CONDYLE ELEMENT SHAFT
29 UN 1 SCRE0078 INCISAL TABLE SCREW
30 UN 1 SCRE0082 MOUNTING PLATE SCREW (LOWER)
31 UN 2 FPIN0744 STABILIZING ELASTIC BAND PIN
Item Unit Qtd. Code Description
14
