13 - PART LIST - STANDARD FACE-BOW
Item Qt Code Description
1 2 SBBL0001 Wing screw
2 1 FFIX0362 Piece to fix the cross bar (without hole)
3 2 FMOL0025 Elastic washer
4 1 SEXP0006 Horizontal slide bar
5 1 STAR0005 Cross bar
6 1 FPNZ0020 Nose piece support
7 4 SCRE0020 Face-bow wing screw
8 1 FHST0018 Nose piece shaft
9 1 FBLO0016 Nose piece
10 1 FARC0784 Face-bow arm (Right)
11 1 FAUR0033 Ear piece (Right)
12 1 CETQ0018 Model identification label
13 1 FAUR0032 Ear piece (Left)
14 1 CELA0009 Elastic band
15 1 FARC0785 Face-bow arm (Left)
16 1 FPOR0039 Center nut
17 1 SGDE0007 Bite fork
18 1 FBLO0008 Connection Block (internal)
19 2 FTMP0027 Stopping screw
20 1 FBLO0006 Connection block (external)
21 1 CARR0004 Washer for the block
22 1 FBLO0026 Fork´s connection block
23 1 CPIE0005 Affixing block pin
24 1 FFIX0022 Affixing block (with hole)
17
