Placing smartdot™ transmitter on your pen injector
1. Hold the pen in one hand, so that you can see the dose knob.
2. In your other hand, hold the smartdot™ transmitter by the dial wheel.
3. Place the transmitter onto the dose knob and push the dial wheel down
until the dose knob is completely covered by smartdot™ transmitter, and
you cannot push anymore.
Do not hold or push the injection button when placing it onto the pen
injector.
smartdot
TM
transmitter should cover
the pen dose knob entirely
Part 5: Preparing
D
Note:
The smartdot™ transmitter can be placed on the pen in any
orientation. The transmitter intended use is to record the injection
data, it does not indicate how to inject.
11
