INSTALLING THE OPTIONAL SEAT BELT AND BUCKLE
(Refer to Figure 4.)
Tools Required:
5/8” Wrench
To install the optional seat belt and buckle, coat one of the two 7/16-20 hex head bolts supplied
with Loctite 242. Align the pre-drilled hole in the seat belt assembly with the hole on the patient
left side of the seat base and then secure the belt assembly to the seat using the washer and bolt.
The buckle assembly is secured in the same manner on the patient right side of the seat.
INSTALLING THE OPTIONAL EZ-GRIP HANDGRIPS
(Refer to Figure 4.)
The optional EZ-Grip Handgrips come with a left and a right, they are not interchangeable.
When properly installed, the flat side of the grip will face to the inside of the BioStep with the
widest part of the handgrip on the bottom and pointing toward the patient.
To install each handgrip, lift up on the plastic tab and pull the two halves in opposite directions
to open. Position the handgrip with the wide end at the bottom and pointing toward the patient,
then squeeze the two halves toward each other until they lock together.
INSTALLING THE OPTIONAL FOOT STRAPS
To install the optional foot straps, slide the hook side of the strap up through the innermost foot
strap slot and fasten the strap to itself. Take the remaining end of the strap and feed it down
through the remaining foot strap slot and around the outside of the foot plate before fastening
the Velcro to itself.
— 33 — OPTIONAL
