The optional Stabilization Kit (950-245) provides flip-up/flip-down arm rests, a seat belt and
buckle, and a pair of foot straps to help stabilize patients on both the BioStep and BioStep
Clinical Pro Semi-Recumbent Elliptical. All components of the kit are easy to install.
Figure 4: Installing the optional Stabilization Kit.
INSTALLING THE OPTIONAL ARM RESTS
(Refer to Figure 4.)
Tools Required:
Allen Key (supplied)
The optional Arm Rests are designed so they can be lifted up and out of the patient’s way when
not needed. For each of the two arm rests, simply align the three pre-drilled holes on the back of
the folding arm rest support plate with the three pre-drilled holes in the seat back. Use the
screws and Allen key supplied to tightly secure each arm rest plate to the seat back.
14. OPTIONAL
OPTIONAL — 32 —
