3. Walk on the treadmill at
1.0 mph and stop the
treadbelt with your foot.
Front roller should slip
under the treadbelt.
(See Figure 11.7 and 11.8)
Figure 11.7. Treadmill shown without cover.
Note the location of front roller.
Front roller
Figure 11.8. Close up of motor, showing front roller.
CONTENTS
— 11-5 — MAINTENANCE
