9. Configuration and Diagnostics
Configuration Setup Mode
1. With power off to the display
2. Pedal the unit so that the display turns on.
3. Press and hold both the <Set Effort Level> button and the “yy | >” <play pause>
button simultaneously.
4. The first thing shown is the resistance mode.
5. Pressing the +/- <Adjust> buttons toggles through the three modes (iSo, CrES, Cpor)
6. Press the “yy | >” <play pause> button.
7. The next displayed configuration setting is English or metric units.
8. Pressing the +/- <Adjust> buttons toggles through the two selections (EngL, Euro)
9. Press the “yy | >” <play pause> button.
10. The next displayed configuration setting is product type.
11. Pressing the +/- <Adjust> buttons toggles through the two selections (bio, ubC)
12. The next displayed configuration setting is brake type.
13. Pressing the +/- <Adjust> buttons toggles through the two selections (LIt, BIG)
14. Press the “yy | >” <play pause> button.
15. The next displayed configuration setting is the gear ratio.
16. Pressing the +/- <Adjust> buttons toggles through the two selections (10:1, 8:1)
17. Press the “yy | >” <play pause> button.
18. The next displayed configuration setting is the turn on start speed in RPM in RPM.
19. Pressing the +/- <Adjust> buttons toggles through the range of values that
determines the speed in RPM that has to be achieved before the display will turn
on (0-50 RPM).
20. Press the “yy | >” <play pause> button.
21. The top window displays beeP.
22. Pressing the +/- <Adjust> buttons toggles through the three modes (P_on, on, oFF)
23. Press the “yy | >” <play pause> button.
24. A long beep sounds. This indicates that the settings are saved.
Diagnostic Debug Mode
1. With power off to the display
2. Pedal the unit so that the display turns on.
3. Press and hold both the <Set Weight> button and the “yy | >” <play pause>
button simultaneously.
4. The firmware version is displayed in the upper window.
5. Press the “yy | >” <play pause> button.
6. The upper window displays HrS and the lower display shows the number of hours of operation.
7. Press the “yy | >” <play pause> button.
8. The PWM value is displayed in the lower window and “LOAD” is displayed in
the upper window.
9. Pressing the +/- <Adjust> buttons scrolls the PWM value either up or down.
10. Press the “yy | >” <play pause> button.
11. The letters EE are displayed in the upper window.
12. Pressing the +/- <Adjust> buttons scrolls the EEprom address showing the value
at that address location in the lower window.
13. Press the “yy | >” <play pause> button.
14. The letters Atod are displayed in the upper window.
15. A/D counts are shown in the lower window.
16. Press the “yy | >” <play pause> button.
17. The LED test is performed.
18. Press the “yy | >” <play pause> button.
19. A long beep sounds. This indicates that the settings are saved.
— 25 — CONFIGURATIONS AND DIAGNOSTICS
