The Biodex UBCs are easy to adjust for patient comfort. The seat can be moved forward
or back and the arm cranks can be adjusted for comfortable and efficient exercise. The
following section explains how to adjust your bike for optimum patient comfort and
positioning.
Seat Front-to-Back Adjustment: The seat can be moved forward or back over a range of
20" to match user comfort requirements.
To adjust the seat front-to-back position:
• Pull out on the seat front-to-back release handle. While holding the handle out, slide
the seat either forward or back to the desired position. To lock the seat in position,
release the handle and make sure it engages in the appropriate hole. To ensure
reproducible positioning, note the seat position as per the Seat Front-to-Back Position
Scale, located on the seat slide track. The seat is easily moved, even while the user is
seated.
Removing the Seat: The UBC seat is easily removed to accommodate wheelchair-bound users.
To remove the seat:
• Remove the rear seat stop.
• Pull out on the seat front-to-back release handle and slide the seat off the back of
the trolly. You can now easily position a wheelchair patient for exercise.
NOTE: Do not sit on seat when removed.
Actuator Tilt: The actuator can be tilted over a range of 21" to accommodate
patients large and small.
To adjust the actuator tilt:
• Loosen the actuator adjust locking knob by turning it in a counterclockwise direction.
Tilt the actuator to the desired angle. Tighten the locking knob to secure the actuator
in position.
• To ensure reproducible positioning, note the actuator tilt position on the actuator tilt scale.
Arm Crank Length: Arm crank length is adjustable over a range of 10 inches.
To adjust position of the arm cranks:
• Loosen either Arm crank locking knob by turning it in a counterclockwise direction.
Adjust the arm crank to the desired length and tighten the locking knob to secure.
Perform the identical procedure on the opposite arm crank.
ROTATING SEAT (Clinical Pro only)
To aid the user in getting on and off the UBC Clinical Pro's rotational seat can be turned
left or right. This seat also features a safety belt and sturdy grab rails for added patient
security -especially for patients with balance deficiency and palsy.
To rotate the seat:
• Pull forward on the seat rotation handle to release the seat. You may now swivel the
seat left or right until it engages in either position.
• With the seat locked in the desired position, instruct the patient to sit down. Pull out
on the seat rotation handle and rotate the seat until it engages in the forward locked
position.
PARTS AND ADJUSTMENTS — 6 —
