System Components
BATTERY PACK AND BATTERY CHARGER
TheBiomet
®
SpinalPak
®
Non-invasiveSpineFusionStimulatorSystemincludestworechargeablebatterypacks.
Uponreceipt,itisrecommendedthatthesecondbatterypackbeimmediatelyplacedintothechargercradleandfully
charged.Inthemeantimethefirstbatterypackmaybeusedtobeginyourtreatment.
Note: The first battery pack may not provide a 24-hour treatment initially. It is recommended that the patient keep one
battery pack in the battery charger cradle to assure that it is fully charged and ready, and the other inserted into the
Biomet
®
SpinalPak
®
Non-invasive Spine Fusion Stimulator System. This will ensure continuous treatment prescribed by
the prescribing physician.
ThebatterychargerandcradlearedesignedtorechargetheBiomet
®
SpinalPak
®
Non-invasiveSpineFusionStimulator
Systembatterypacksonly.TwoLED(lightemittingdiode)lightsmonitorandindicatetheoperationalstatusofthebattery
charger.TheA/CPowerindicatorlightislocatedontheA/CAdaptor.Thechargingstatusindicatorlightislocatedonthe
chargercradle.ThefollowingtablelistsanddescribestheoperationalfunctionsoftheLEDlights:
Electrodes
Therearetwotypesofelectrodes thatarepackagedwiththeBiomet
®
SpinalPak
®
Non-invasiveSpine
FusionStimulatorSystemassembly:72RandLT-4500.The72Relectrodeshavegreenwritingontheir
packaging.TheLT-4500electrodeshaveblackwritingontheirpackaging.The72Relectrodeshavea
hydrogelthatisstickierthantheLT-4500electrodehydrogel.Thepatientcanusewhicheverelectrodes
bestsuittheirskintype.
Electrode Covers
Theelectrodecoversarewaterresistantandareintendedtoenhanceelectrodesecuritytotheskin,if
needed,orforshoweringwiththeelectrodesattached,ifdesired.
Device Holster
ThedeviceholsterisdesignedtosecurelyholdtheBiomet
®
SpinalPak
®
Non-invasiveSpineFusion
StimulatorSysteminplace.Ithasacliponthebackwhichallowsthepatienttowearthedeviceon
theirwaistbandorbelt.
Lead Wires
TwodifferentlengthleadwiresareincludedwiththeBiomet
®
SpinalPak
®
Non-invasiveSpineFusion
StimulatorSystem.Thepatientshouldchoosetheleadwirethatbestaccommodatestheirneedsfor
wheretheywouldliketowearthecontrolunit.
Following are possible error conditions and possible resolutions.
Status
A/C Power
Indicator Light
Charging Status Indicator
Light on Cradle
Nobatterypackinserted
(idle)onA/Cpowered
batterycharger
Solidgreen Off
Batterypackinchargingstate Solidgreen Solidorange
Fullychargedbatterypack Solidgreen Solidgreen
A/Cpowerdeficiency Off Off
Error Solidgreen Off
Error Conditions (flashes orange) Possible Resolutions
Batterypacknotproperlyconnected
tothecharger
Removeandre-installthebatterypackto
ensureacompleteconnectiontothecharger
Batterytemperatureistooloworhigh Normaloperatingtemperatureis
5°Cto38°C[41°F-100°F]
Batteryvoltageistoolow CallBiometforanewbatterypack
