bioMetric SpinalPak - Operating Instructions; STEP 1: INSERT BATTERY PACK; STEP 2: ATTACH ELECTRODES; Charging the Battery Pack

6 7
Operating Instructions
Both battery packs provided with the Biomet
®
 SpinalPak
®
Non-invasive Spine Fusion Stimulator
Systemarechargedpriortobeingpackagedanddistributed.UponreceiptoftheBiomet
®
SpinalPak
®
Non-invasive Spine Fusion Stimulator System, it is recommended that the second battery pack be
immediatelyplacedintothechargercradleandcompletelycharged.Inthemeantime,thefirstbattery
packmaybeusedtobeginyourtreatmentimmediately.Note: The first battery pack may not provide
a complete 24-hour treatment initially.
STEP 1:
Following the arrows, insert the charged battery pack
(1,2)intotheBiomet
®
SpinalPak
®
Non-invasiveSpineFusion
Stimulator System (Figure 4). The LED light on top of the
device will blink, indicating power. Each symbol will be
indicatedonthedisplayandthealarmwillflashandbeepif
theelectrodesarenotproperlyapplied.Tosilencetheaudio
alarmpressthebuttonbelowthedisplay.
If the light does not blink, which indicates that the battery
packisnotcharged,changethebatterypack
(SeeChargingtheBatteryPackbelow).
STEP 2:
Attach electrodes as per instructions on
Page10, and as per “To Begin Treatment -
ElectrodePlacement”sectiononpage6.
Charging the Battery Pack
Chargethebatterypackatroomtemperature(24°C(75°F)).Chargingmayrequiretwotothreehours.
Chargingmayvaryinwarmerorcoldertemperatures.
STEP 1:
Plugthebatterypackchargerandcradleintoawalloutlet(Figure5).AgreenlightontheA/Cadaptor
willilluminateindicatingpower(Figure6).
Figure 4
Figure 5
Figure 6
