A785G3/A780L3/A780L3G BIOS Manual
30
CPU FID/VID Control
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
CPU FID/VID Control
Custom P-States [Disabled]
Core FID [x14.0 2800MHz]
Core VID [1.2500 V]
Core DID [Divided by 1]
NB VID [1.2000 V]
NB FID [2000 MHZ]
Performance
Tells BIOS whether to
use the setup options
below this to
configure the
P-States, or whether
to configure the
P-States automatically
Custom P-States
This item allows you to select the P-States controlling.
Options: Disabled (Default) / Enabled
Core FID
This item allows you to select the Ratio/Frequency of AM3 CPU.
Options: x8.0 1600MHz ~ x31.5 6300MHz
Core VID
This function allows you to adjust the voltage of AM3 CPU.
Options: 0.0125V ~ 1.5500V
Core DID
This is the Core Divider.
Options: Divided by 1 (Default) / Divided by 2 / Divided by 4 / Divided by 8 /
Divided by 16
To Next Page
