A785G3/A780L3/A780L3G BIOS Manual
31
NB VID
This function allows you to adjust the voltage of NB chip.
Options: 0.0125V ~ 1.5500V
NB FID
This item allows you to select the Frequency of NB chip.
Options: 800MHz ~ 7000MHz (Differed by CPU)
Hyper Transport Configuration
BIOS SETU P UTILITY
vxx .xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Hyper Transpor t Configuration
NODE0:PCI-X2 HT Link
HT Link Speed [Auto]
HT Link Width [Auto]
The Hypertransport
link will run at this
speed if it is slower
than or equal to the
system clock and the
board is capable.
Performance
HT Link Speed
Options: Auto (Default) / 200MHz / 400MHz / 600MHz / 800MHz / 1GHz /
1.2GHz / 1.4GHz / 1.6GHz / 1.8GHz / 2.0GHz / 2.2GHz / 2.4GHz /
2.6GHz
HT Link Width
Options: Auto (Default) / 8 Bit / 16 Bit
