Biostar B150GTN User Manual

4 | Chapter 1: Introducon
1�3 Specicaons
Specicaons
CPU Support
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset
INTEL® B150 (B150GTN)
INTEL® H170 (H170GTN)
INTEL® Z170 (Z170GTN)
Memory
Supports Dual Channel DDR4 2133/1866
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
4x SATA III (6Gb/s)
1x PCIe 3.0 x4 U.2 Connector (32Gb/s)
1x PCIe 3.0 x4 M.2 (Key M) Slot (32Gb/s)
supports RAID 0,1,10, 5 & AHCI (H170GTN & Z170GTN)
supports AHCI (B150GTN)
LAN
Intel i219V
1x 10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC892
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
6x USB 3.0 port (4 on rear I/Os and 2 via internal headers)
4x USB 2.0 port (2 on rear I/Os and 2 via internal headers)
Expansion Slots
1x PCIe 3.0 x16 Slot (x16)
1x PCIe 3.0 x1 M.2 (Key E) Slot (H170GTN & Z170GTN)
Rear I/Os
1x PS/2 Mouse or Keyboard
1x DVI-D Port
1x HDMI Port
4x USB 3.0 Port
2x USB 2.0 Port
1x LAN port
5x Audio Jack
1x S/PDIF out port
Internal I/Os
4x SATA III (6Gb/s)
1x PCIe 3.0 x4 U.2 Connector (32Gb/s)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
2x USB 3.0 Header (each header supports 2 USB 3.0 ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
Form Factor Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 7/ 8.1(64bit)/ 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.

Biostar B150GTN Specifications

General

Brand	Biostar
Model	B150GTN
Category	Motherboard
Language	English
