1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket 1155
Inte l Core i7 / i5 / i3 / Pent ium / C eleron
processor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyp er Thr eading
Chipset
Intel B75
Super I/O
IT8728
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives ,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "Smart Guard ian" funct ion
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 32GB
Each DIMM supports 512MB/
1GB/2GB/4GB/8GB DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 1066 / 1333
Supports DDR3 1600 (Depending on CPU)
Registered DIMM and ECC DIMM is not supported
SATA 2 & 3
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
LAN
Realtek RTL 8111F
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
USB3.0
B75 Data transfer rates up to 600 MB/s
PCI Express Gen3 x 16 slot
(Depending on CPU) x1
Supports PCI-E Gen3 x16 expansion card
PCI slot x2 Supports PCI expansion cards
Slots
PCI Express Gen2 x 1 slot x1 Supports PCI-E Gen2 x1 expansion cards
SATA3 Connector x1 Each connector supports 1 SATA3 devices
SATA2 Connector x5 Each connector supports 1 SATA2 devices
Front Panel Connector x1 Supports front panel facilities
On Board
Connectors
Front Audio Connector x1 Supports front panel audio function

Biostar B75MU3 Specifications

General

Brand	Biostar
Model	B75MU3
Category	Motherboard
Language	English
