Chapter 2: Hardware installaon | 9
B760MX-E D4｜B760MH D4｜B760MX2-E D4
Step 4: Close the load plate.
Step 5: Remove and save cover.
Step 6: Close ILM Lever and latch
Note
» 
»
Ensure that you install the correct CPU designed for LGA1700 socket.
» 
»
The CPU ts only in one correct orientaon. Do not force the CPU into the socket to prevent 
damaging the CPU.
