10
2.
4
C
ONNEC
T
O
RS
AND
S
LOTS
SA
T
A
1~SA
T
A
4:
Serial A
T
A
Connector
s
T
he m
otherboard has a PCI
to SA
TA
Controller with 4 channels SA
TA2 interface,
it satisfies the SA
TA
2.0 spec and with transfer rate of 3.0Gb/s.
Pin
A
ssignment
1 Ground
2 TX
+
3 TX
-
4 Ground
5 RX
-
6 RX
+
7 Ground
AT
XP
W
R2
:
AT
X P
o
w
e
r S
o
u
rc
e
C
o
n
n
e
c
t
o
r
T
his connector provides +
12V
to CPU power circuit.
Pin
A
ssignment
1 +12V
2 +12V
3 Ground
4 Ground
11
13
