H61MGV3 / H61MLV3 UEFI BIOS Manual
27
DDR3 DRAM Timing Control
This item allows you to choose to manually or automatically regulate the
DRAM Timing.
Options: By SPD (Default) / Manual / XMP Profile 1 / XMP Profile 2
DDR3 DRAM Multiplier
This item allows you to set DDR3 DRAM Multiplier.
DDR3 DRAM Command Rate
This item allows you to set DDR3 DRAM Multiplier.
Options: Auto (Default) / 1T / 2T
CAS# Latency (tCL)
This item allows you to select CAS Latency of DDR3.
Options: 7 (Default) / 3 ~ 15
Row Precharge Time (tRP)
This item allows you to select Row Precharge Time of DDR3.
Options: 7 (Default) / 3 ~ 15
RAS# to CAS# Delay (tRCD)
This item allows you to select Row Address to Column Address Delay of
DDR3.
Options: 7 (Default) / 3 ~ 15
RAS# Active Time (tRAS)
This item allows you to select Row Active Time of DDR3.
Options: 20 (Default) / 9 ~ 63
Write Recovery Time (tWR)
This item allows you to select Internal Write to Read Command Delay of
DDR3.
Options: 8 (Default) / 3 ~ 31
Row Refresh Cycle Time (tRFC)
This item allows you to select Minimum Refresh Recovery Time of DDR3.
Options: 59 (Default) / 15 ~ 255
