Biostar Hi-Fi A70U3P User Manual

Motherboard Manual
6
Step 4: Hold the CPU down firmly, and then close the lever to locked the
position
2.2 Install a Heatsink
Step 1: Place the heatsink and fan assembly onto the retention frame. Match the
heatsink clip with the socket mounting-lug. Hook the spring clip to the
mounting-lug.
Step 2: On the other side, push the retention clip straight down to lock into the
plastic lug on the retention frame, and then press down the locker until it
stops.
Note1: Do not forget to connect the CPU fan connector.
Note2: For proper installation, please kindly refer to the installation manual of your CPU
heatsink.

Biostar Hi-Fi A70U3P Specifications

General

Form Factor	Micro ATX
Chipset	AMD A70M
Socket	FM2+
Memory Type	DDR3
Memory Slots	2
Maximum Memory	32 GB
PCIe Slots	1 x PCIe 2.0 x1
SATA Ports	4 x SATA 6Gb/s
USB Ports	8 x USB 2.0
LAN	Realtek RTL8111 Gigabit LAN
