1.3 Motherboard Specifications
Specifications
CPU Support
Socket 1150 for Intel® Core i7 / i5 / i3 / Pentium / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Watt
* Please refer to
www.biostar.com.tw for CPU support list.
Chipset INTEL® B85 (Hi-Fi B85N 3D) INTEL® H81 (Hi-Fi H81N 3D)
Memory
Supports Dual Channel DDR3 1066/ 1333/ 1600
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to
www.biostar.com.tw for Memory support list.
Storage
INTEL® B85:
2x SATA 6Gb/s Connector
2x SATA 3Gb/s Connector
1x mSATA Connector
Supports AHCI
INTEL® H81:
1x SATA 6Gb/s Connector
2x SATA 3Gb/s Connector
1x mSATA Connector
Supports AHCI
LAN
2x Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec
ALC892
7.1 Channels, High Definition Audio, Biostar Hi-Fi
USB
INTEL® B85:
4x USB 3.0 port (2 on rear I/Os and 2 via
internal headers)
8x USB 2.0 port (4 on rear I/Os and 4 via
internal headers)
INTEL® H81:
2x USB 3.0 port (2 on rear I/Os)
8x USB 2.0 port (4 on rear I/Os and 4 via
internal headers)
Expansion Slots
1x PCIe 3.0 x16 Slot (x16), Hi-Fi B85N 3D
1x PCIe 2.0 x16 Slot (x16), Hi-Fi H81N 3D
Rear I/Os
1x PS/2 Mouse/Keyboard
1x HDMI Port
1x VGA Port
1x DVI Port
2x LAN port
4x USB 2.0 Port
2x USB 3.0 Port
5x Audio Jack
1x S/PDIF out
Internal I/Os
Hi-Fi B85N 3D
2x SATA 6.0Gb/s Connector
2x SATA 3.0Gb/s Connector
1x mSATA Connector
2x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
1x USB 3.0 Header
Hi-Fi H81N 3D
1x SATA 6.0Gb/s Connector
2x SATA 3.0Gb/s Connector
1x mSATA Connector
2x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
