Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
JKBMS1
JCOM1
JVGA1
JUSB1
JUSBLAN1
JAUDIO1
Super I/O
Codec
JCDIN1 JSPDIF_OUT1 JSFAN1 JUSB3JUSB2
JPANEL1
JSATA2
JSATA1
JCMOS1
BAT1
IDE1
IDE2
JATXPWR1
FDD1
DIMMA1
DIMMB1
Socket A M2
K8M800
JPRNT1
LAN
PCI1
PCI2
BIOS
AGP1
JATXPWR2
JAUDIO2
VT8237R+
JCFAN1
Note: ■ represents the 1
st
pin.
