M7VIZ BIOS Setup
30
9 Frequency/ Voltage Control
Figure 9. Frequency/ Voltage Control
CPU Clock
This item allows you to select CPU Clock, and CPU over clocking.
If unfortunately, the system’s frequency that you are selected is
not functioning, there are two methods of booting-up the system.
Method 1: Clear the COMS data by setting the JCOMS1 ((2-3) closed))
as “ON” status. All the CMOS data will be loaded as
defaults setting.
Method 2: Press the <Insert> key and Power button simultaneously,
after that keep-on pressing the <Insert> key until the
power-on screen showed. This action will boot-up the
system according to FSB of the processor.
※ It’s stron
l
recommended to set CPU Vcore and clock in
default settin
. If the CPU Vcore and clock are not in default
setting, it may cause CPU or M/B damage.
