N68S3B BIOS Manual
31
DRAM Timing Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
DRAM Timing Configuration
Memory Clock Mode [Auto]
Memclock Value [Auto]
DRAM Timing Mode [Auto]
Memory CLK :
CAS Latency(Tcl) :
RAS/CAS Delay(Trcd) :
Row Precharge Time(Trp):
Min Active RAS(Tras) :
RAS/RAS Delay(Trrd) :
Row Cycle (Trc) :
Write Recover Time(Twr):
Select the DRAM
Frequency programming
method. If Auto,
the DRAM speed will
be based on SPDs.
If Limit, the DRAM spe
will not exceed the
specified value. If
Manual, the DRAM speed
specified will be
programmed regardless.
Performance
Memory Clock Mode
This item allows you to control the Memory Clock.
Options: Auto (Default) / Limit / Manual
Memclock Value
This item allows you to set the Memory Clock.
Options: Auto (Default) / DDR3-800 / DDR3-1066 / DDR3-1333 / DDR3-1600
DRAM Timing M ode
This item allows you to choose to manually or automatically regul ate the DRAM
Timing.
Options: Auto (Default) / DCT0 / DCT1 / Both
CAS Latency (CL)
Options: Auto (Default) / 4~12 CLK
2T Command
Options: Auto (Default) / 1T / 2T
TR CD
Options: Auto (Default) / 5~12 CLK
