P4M80-M4
17
JCI1: Chassi
s Open Header
This connector allows system to monitor PC case op
en status. If the signal has
been triggered, it will record to the CMOS and show the message on next
boot-up.
Pin
Assignment
1 Case
open
signal
12
PU
2 Ground
18
20
