V6 Tech Engine
This engine will make a good over-clock performance.
BIOS SETUP UTILITY
Main Advan ced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C)Copyright 19 85-200x , American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause sys tem to malfunction.
=========== Automate Over Clock System ==== =======
============ Manual Ov erClock System ============
OverClock Navigator [Automate OverClock]
Integrated Memory Test [Disabled]
Auto OverClock System [V6-Tech Engine]
CPU Over Voltage [StartUp]
Memory Over Voltage [1.95V]
Chipset Over Voltage [1.15V]
HT Over Voltage [1.20V]
CPU Frequency [200]
> CPU FID/VID Control
> Memory Configuration
> DRAM Timing Configur ation
> Hyper Transport Conf iguration
Exit
Options
V6-Tech Engine
V8-Tech Engine
V12-Tech Engine
V8 Tech Engine
This engine will make a better over-clock performance.
BIOS SETUP UTILITY
Main Advan ced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C)Copyright 19 85-200x , American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause sys tem to malfunction.
=========== Automate Over Clock System ==== =======
============ Manual Ov erClock System ============
OverClock Navigator [Automate OverClock]
Integrated Memory Test [Disabled]
Auto OverClock System [V8-Tech Engine]
CPU Over Voltage [StartUp]
Memory Over Voltage [1.95V]
Chipset Over Voltage [1.15V]
HT Over Voltage [1.20V]
CPU Frequency [200]
> CPU FID/VID Control
> Memory Configuration
> DRAM Timing Configur ation
> Hyper Transport Conf iguration
Exit
Options
V6-Tech Engine
V8-Tech Engine
V12-Tech Engine
V12 Tech Engine
This engine will make a best over-clock performance.
BIOS SETUP UTILITY
Main Advan ced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C)Copyright 19 85-200x , American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause sys tem to malfunction.
=========== Automate Over Clock System ==== =======
============ Manual Ov erClock System ============
OverClock Navigator [Automate OverClock]
Integrated Memory Test [Disabled]
Auto OverClock System [V12-Tech Engine]
CPU Over Voltage [StartUp]
Memory Over Voltage [1.95V]
Chipset Over Voltage [1.15V]
HT Over Voltage [1.20V]
CPU Frequency [200]
> CPU FID/VID Control
> Memory Configuration
> DRAM Timing Configur ation
> Hyper Transport Conf iguration
Exit
Options
V6-Tech Engine
V8-Tech Engine
V12-Tech Engine
