Notices:
1. Not all types of AMD CPU perform above overclock setting ideally; the difference will be based
on the selected CPU model.
B. Memory Integration Test (M.I.T.)
This function is under “Overclocking Navigator Engine” item.
MIT allows users to test memory compatibilities, and no extra devices or
software are needed.
Step 1
The default setting under this item is “Disabled”; the condition parameter should
be changed to “Enable” to proceed this test.
BIOS SETUP UTILITY
Main Advan ced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C)Copyright 19 85-200x , American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause sys tem to malfunction.
=========== Automate Over Clock System ==== =======
============ Manual Ov erClock System ============
OverClock Navigator [Normal]
Auto OverClock System [V6-Tech Engine]
CPU Over Voltage [StartUp]
Memory Over Voltage [1.95V]
Chipset Over Voltage [1.15V]
HT Over Voltage [1.20V]
CPU Frequency [200]
> CPU FID/VID Control
> Memory Configuration
> DRAM Timing Configur ation
> Hyper Transport Conf iguration
Integrated Memory Test [Disabled]
Exit
Options
Enabled
Disabled
↓
BIOS SETUP UTILITY
Main Advan ced PCIPnP Boot Chipset T-Ser ies
vxx.xx (C)Copyright 19 85-200x , American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
T-Series Settings
WARNING: Setting wrong values in below sections
may cause sys tem to malfunction.
=========== Automate Over Clock System ==== =======
============ Manual Ov erClock System ============
OverClock Navigator [Normal]
Auto OverClock System [V6-Tech Engine]
CPU Over Voltage [StartUp]
Memory Over Voltage [1.95V]
Chipset Over Voltage [1.15V]
HT Over Voltage [1.20V]
CPU Frequency [200]
> CPU FID/VID Control
> Memory Configuration
> DRAM Timing Configur ation
> Hyper Transport Conf iguration
Integrated Memory Test [Enabled]
Exit
Options
Enabled
Disabled
Step 2
Save and Exit from CMOS setup and reboot the system to activate this test.
Run this test for 5 minutes (minimum) to ensure the memory stability.
Step 3
When the process is done, change the setting back from “Enable” to “Disable”
to complete the test.
