Biostar TA870 User Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Sempron / Phenom II / Athlon II
processors (Maximum Watt: 125W)
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 870
AMD SB850
Super I/O
ITE 8721
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
H/W Monitor
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 512MB/
1GB/2GB/4GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800 / 1066 / 1333
Supports DDR3 1600 (OC)
SATA III
Integrated Serial ATA Controller
Data transfer rates up to 6 Gb/s.
SATA Version 3.0 specificat ion co mp liant.
RAID 0,1,5,10 support
LAN
Realtek RTL 8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
ALC662
5.1channels audio out
Supports HD Audio
PCI Slot x2 Supports PCI expansion cards
PCI Express Gen2 x1 Slot x2 Supports PCI-E Gen2 x1 expans ion card
Slots
PCI Express Gen2 x16 Slot x2 Supports PCI-E Gen2 x16, x4 expansion cards
SATA Connector x6 Each connector supports 1 SATA device
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CD-in Connector x1 Supports CD audio-in function
On Board
Connectors
S/PDIF out Connector x1 Supports digital audio out function

Biostar TA870 Specifications

General

Brand	Biostar
Model	TA870
Category	Motherboard
Language	English
