Notices:
Not all types of Intel CPU perform above overclock setting ideally; the difference will be based on the
selected CPU model.
B. Memory Integration Test (M.I.T.)
This function is under “Overclocking Navigator Engine” item.
MIT allows users to test memory compatibilities, and no extra devices or
software are needed.
Step 1
The default setting under this item is “HotKey F11”; the condition parameter
should be changed to “Enable” to proceed this test.
BIOS SETUP UTILITY
Main Advanced
PCIPnP Boot
Chipset O.N.E
vxx.xx (C)Copyright 198 5-200x, American Meg atrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Auto OverClock Syst em [V 6-Tech Engine]
Current CPU Frequen cy :
Current Memory Freq uency :
Current UNCORE Freq uency :
Currnet QPI Frequen cy :
Over Clock Retry Co unt [1 ]
Intel(R) SpeedStep( tm) tech [E nabled]
CPU Ratio Setting [ x24.0]
CPU Frequency Setti ng [1 33]
QPI Frequency [A uto]
DRAM Frequency [A uto]
> DRAM Timing Confi guration
> Clock Gen Configu ration
> Voltage Control
> Intel PPM Configu ration
> BIOSTAR Memory In sight
> G.P.U Phase Contr ol
============ Manual OverClock Sys tem ============
Integrated Memory T est [H otKey F11]
Exit
Options
HotKey F11
Disabled
Enabled
↓
BIOS SETUP UTILITY
Main Advanced
PCIPnP Boot
Chipset O.N.E
vxx.xx (C)Copyright 198 5-200x, American Meg atrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Auto OverClock Syst em [V 6-Tech Engine]
Current CPU Frequen cy :
Current Memory Freq uency :
Current UNCORE Freq uency :
Currnet QPI Frequen cy :
Over Clock Retry Co unt [1 ]
Intel(R) SpeedStep( tm) tech [E nabled]
CPU Ratio Setting [ x24.0]
CPU Frequency Setti ng [1 33]
QPI Frequency [A uto]
DRAM Frequency [A uto]
> DRAM Timing Confi guration
> Clock Gen Configu ration
> Voltage Control
> Intel PPM Configu ration
> BIOSTAR Memory In sight
> G.P.U Phase Contr ol
============ Manual O verClock System ===== =======
Integrated Memory T est [E nabled]
Exit
Options
HotKey F11
Disabled
Enabled
Step 2
Save and Exit from CMOS setup and reboot the system to activate this test.
Run this test for 5 minutes (minimum) to ensure the memory stability.
Step 3
When the process is done, change the setting back from “Enable” to “Disable”
to complete the test.
