Biostar TP55 User Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket 1156
Intel Core i7 / i5 pro ces sor
Supports Execute D isable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Chipset
Intel P55
Super I/O
IT8720
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
Main
Memory
DDR3 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 512MB/ 1GB/2GB/4GB
DDR3
Dual Channel Mode DDR3 memory modu le
Supports DDR3 800 / 1066 / 1333
Supports DDR3 1600 (OC) / 1866 (OC)
Registered DIMM and ECC DIMM is not
supported
IDE
JMB368
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA 2
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 spec if icat ion co mp liant
LAN
Realtek RTL 8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC662
5.1 channels audio out
High Definition Audio
PCI slot x2 Supports PCI expansion cards
PCI Express Gen2 x 16 slot x1 Supports PCI-E Gen2 x16 expansion card
Slots
PCI Express Gen2 x 1 slot x2 Supports PCI-E Gen2 x1 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
On Board
Connectors
SATA Connector x6 Each connector supports 1 SATA devices

Biostar TP55 Specifications

General

Brand	Biostar
Model	TP55
Category	Motherboard
Language	English
