Chapter 2: Hardware installaon | 11
X570GT
2.4 Install System Memory
DDR4 Modules
Step 1: Unlock a DIMM slot by pressing the
retaining clips outward. Align a DIMM on the
slot such that the notch on the DIMM matches
the break on the slot.
Step 2: Insert the DIMM vercally and
rmly into the slot unl the retaining clips
snap back in place and the DIMM is properly
seated.
Note
»
IftheDIMMdoesnotgoinsmoothly,donotforceit.Pullitallthewayoutandtryagain.
Memory Capacity
DIMM Socket Locaon DDR4 Module Total Memory Size
DIMMA1 8GB/16GB/32GB
Max is 128GB.
DIMMA2 8GB/16GB/32GB
DIMMB1 8GB/16GB/32GB
DIMMB2 8GB/16GB/32GB
Dual Channel Memory Installaon
Please refer to the following requirements to acvate Dual Channel funcon:
Install memory module of the same density in pairs, shown in the table.
Dual Channel Status DIMMA1 DIMMA2 DIMMB1 DIMMB2
Enabled O X O X
Enabled X O X O
Enabled O O O O
(O means memory installed, X means memory not installed.)
Note
»
Wheninstallingmorethanonememorymodule,werecommendtousethesamebrandand
capacitymemoryonthismotherboard.
To Next Page
