1�3 Specifications
Specicaons
CPU Support
Socket AM4 supports AMD® Ryzen APU / Ryzen CPU
Maximum CPU TDP (Thermal Design Power): 105Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset AMD® X570
Memory
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2667
Supports Dual Channel DDR4 2933(OC)/ 3200(OC)/ 3600(OC)/ 4000+(OC)
4 x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB Memory
Each DIMM supports non-ECC and ECC Un-buered 8/ 16/ 32 GB DDR4 module
* DDR4 - 2667 only for Ryzen CPU.
* Please refer to www.biostar.com.tw for Memory support list.
Storage
4x SATA III Connector (6Gb/s): Supports RAID 0, 1, 10
1x M.2 (Key M) Slot (PCIE-M2) :
Supports M.2 Type 2242/ 2260/ 2280 SSD module
Supports SATA III (6.0Gb/s) SSD
Supports PCI-E Gen4 x4 (64Gb/s) speed, which depends only on Ryzen 3rd Gen Masse.
LAN
RTL8111H
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC887
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
6x USB 3.1 Gen1 (5Gb/s) port (4 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
2x PCIe 3.0 x1 Slot
1x PCIe 4.0 x16 Slot (PEX16_1)
* Note :
Supports x16 lanes with AMD® Ryzen™ 2nd and 3rd Gen processors.
Supports x8 lanes with AMD® Ryzen™ with Radeon Vega Graphics processors.
* According to dierent CPUs will have dierent speeds.
* Note: PCIe 4.0 speed only for AMD® Ryzen™ 3rd Gen Masse.
Rear I/Os
1x PS/2 Keyboard Port
1x HDMI Port
1x VGA Port
1x LAN port
4x USB 3.1 Gen1 (5Gb/s) Port
2x USB 2.0 Port
3x Audio Jack
Internal I/Os
4x SATA III (6.0Gb/s) Connector
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.1 Gen1 (5Gb/s) Header (each header supports 2 USB 3.1 Gen1 ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x System Fan Connector (Southbridge Heatsink Fan Header : This connector is only available for
Southbridge Heatsink Fan.)
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x COM Port Header
2x LED Header (12V/ 5V)
Form Factor uATX Form Factor, 243.95mm x 235mm
OS Support
Windows 10(64bit)
Biostar reserves the right to add or remove support for any OS with or without noce.

Biostar X570GT Ver. 6.x Specifications

General

Brand	Biostar
Model	X570GT Ver. 6.x
Category	Motherboard
Language	English
