20 | Chapter 2: Hardware installaon
5V_LED1/ 5V_LED2: Addressable RGB LED Device (WS2818B) Header
This header providers 5V power and Data control pins for ARGB LED Device (WS2818B).
Pin Assignment
1 VCC5
2 Data
3 N/A
4 GND
Note
»
 EnsureproperpinconnecngtoyourLEDdevice,wrongconneconmaydamageyourLEDdeviceor
motherboard.

»
The12V_LEDconnectorsupportsto5050RGBLEDstripswiththemaximumpowerrangof3A
(12V).

»
The5V_LEDconnectorsupportsupto300LEDsWS2818BindividuallyAddressableRGBLEDstrips
withthemaximumpowerrangof3A(5V).

»
PleaseusetheVividLEDDJsowaretocontroltheLEDs.Fordetailedsowaresenginformaon,
refertochapter3.3.
