BIRD Thruline 4410A500 User Manual

BIRD Thruline 4410A500

38 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Series 4410 Directional RF

Thruline

®

Wattmeter

©Copyright 2011

by Bird Electronic Corporation

Instruction Book Part Number 920-4410S Rev. D

Thruline is a trademark of Bird Electronic Corporation

Table of Contents

Questions and Answers:

H
Haley SalazarAug 11, 2025
What to do if my BIRD Thruline 4410A500 show no meter indication?
- C
  Chad PhillipsAug 11, 2025
  If your BIRD Measuring Instruments aren't showing any meter indication, here are a few things to check: * First, verify the RF source and test the battery, replacing it if necessary due to weakness or failure. * Ensure the arrow on the plug-in element points in the direction of power flow; reposition if needed. * Inspect DC meter leads for open or short circuits and replace them if defective. * If the meter is burned out or the wattmeter is damaged, consider replacing it or returning it to the factory for replacement and recalibration. * Also, check the DC contact finger.
S
Sandra DaltonAug 21, 2025
Why is there a high percentage of reflected power in my BIRD Measuring Instruments?
- L
  Lauren VelazquezAug 21, 2025
  A high percentage of reflected power in your BIRD Measuring Instruments could be due to several reasons: * A bad load or poor connectors may be the cause. Replace the load, antenna, or connectors. * A shorted or open transmission line. In this case, service or replace the line. * Foreign material in the line section or RF connector. Inspect for any foreign material and clean as necessary.
R
Rachel RushAug 31, 2025
How to fix intermittent meter readings on BIRD Thruline 4410A500?
- M
  mcharlesAug 31, 2025
  Inconsistent readings on your BIRD Measuring Instruments can stem from: * A faulty transmission line or load. Inspect the line connections, antenna, or load. * Dirty DC contact on elements. Clean the DC contact. * A sticky or defective meter. Replace the meter or return the wattmeter to the factory for meter replacement and recalibration.

BIRD Thruline 4410A500 Specifications

General

Power Rating	500 W
Impedance	50 Ohms
Accuracy	±5% of full scale
Connector Type	N-type
VSWR	1.05:1
Insertion Loss	≤ 0.1 dB
