Fig.15: Dimensional drawing CSW9563-140Y .. CSW95113-320(Y), CSH9663-160Y .. CSH96113-320Y
A
mm
B
mm
C
mm
D
mm
F
mm
I
mm
J
mm
L
mm
N
mm
CSW9563, CSW9573,
CSH9663, CSH9673
1824 717 776 224 417 41 930 751 118
CSW9583, CSW9593,
CSH9683, CSH9693
1842 717 776 242 417 34 948 751 122
CSW95103-240Y 1927 731 796 242 431 26 948 751 120
CSW95103-280(Y),
CSW95113-280Y,
CSH96103-280Y
1955 731 796 269 431 26 975 751 120
CSW95113-320(Y),
CSH96113-320Y
1974 731 796 289 431 26 994 751 120
