SW-100-86
Sealing screws or plugs with O-ring
Size
1 1/8-18 UNEF 50 Nm
M22 x 1,5 40 Nm
M52 x 1,5 100 Nm
Sealing nuts with O-ring
Thread AF
3/4-16 UNF 22 50 Nm
1-14 UNS 30 85 Nm
1 1/4-12 UNF 36 105 Nm
1 3/4-12 UN 50 150 Nm
2 1/4-12 UN 65 180 Nm
AF: width across flats in mm
Gas permeable plugs
Size
M20 x 1,5 10 Nm
3 Sight glasses
Also mind when mounting or replacing:
• Tighten sight glasses only with calibrated torque
spanner to indicated torque. Do not use a pneumatic
impact wrench.
• Tighten flanges of sight glasses in several steps to
indicated torque.
• Check sight glass visually in detail before and after
mounting.
• Test changed component for tightness.
Sight glasses with sealing flange
Screw size
M8 14 Nm
M10 18 Nm
Sight glasses with union nut
Size AF
1 3/4-12 UN 50 150 Nm
2 1/4-12 UN 65 180 Nm
AF: width across flats in mm
Screwed sight glass
Size
1 1/8-18 UNEF 50 Nm
4 Electrical contacts
DANGER
Danger of electrical shock!
Disconnect supply voltage of compressor.
Size Nut Screw
M4 2 Nm
M5 5 Nm
M6 6 Nm
M8 10 Nm
M10 30 Nm 40 Nm ①
M12 40 Nm ①
M16 40 Nm ①
①: Mount with a pair of wedge lock washers.
Tighten all screwed connections on terminal plate
manually with calibrated torque spanner to indicated
torque. Do not use any pneumatically driven tool.
FI current bars at CSV.
Size
M10 56 Nm
Mount the screwed connection in this order: screw,
washer, FI connection, current bar, pair of wedge lock
washers, nut.
5 Solenoid valves
Fixing nuts of solenoid coil
Size
M10 5 Nm
M14 15 Nm
Screwed connection of electric connector M3: 1Nm
