Bitzer SE-i1 User Manual

CT-110-2 5
CS.65..CS.95,
CSHP*,
HS.53*..HS.85
basic sensor kit
CS.65..CS.95,
HS.64..HS.85
with full sensor kit
SE-i1 as SE-C1
replacement
part number:
34705002
SE-i1 as SE-C2
replacement
part number:
34705004
Protective and monitoring functions
Motor protection functions:
• Motor temperature (PTC)
• Rotation direction
• Phase failure
●
●
●
●
●
●
●
●
●
●
●
●
Oil monitoring:
• CS.: oil level
• HS.53 .. HS.74: oil flow
• HS.85: oil flow / oil stop valve
●
●
●
●
●
●
●
●
●
Warning if the recommended
shut-off periods are not com-
plied with
● ● ● ●
Discharge gas or oil temperat-
ure monitoring (PTC, in series
with motor PTC)
● -- ● ●
Discharge gas or oil temperat-
ure monitoring with absolute
temperature (NTC)
➀ ● ➀ ➀
Monitoring of application limits
(via low pressure and high pres-
sure transmitters)
➀ ● ➀ ➀
Low and high pressure switches ➀ ● ➀ ➀
Settings in the BEST SOFTWARE
Preset parameters Compressor type:
"SE-C1 Replace-
ment" or "SE-C2
Replacement"
Serial number of
the compressor
Compressor type,
serial number of
the compressor
Compressor
type: "SE-C1 Re-
placement"
Compressor
type: "SE-C2 Re-
placement"
Required minimum settings -- Refrigerant, ECO
operation
-- --
Further recommended settings Date and time,
system informa-
tion
Date and time,
system informa-
tion, pressure
switch
Serial number of
the compressor,
date, time, sys-
tem information
Serial number of
the compressor,
date, time, sys-
tem information
Other
Wired and tested when leaving
the factory
● ● -- --
Wire bridge required for unused
oil monitoring inputs ③
Yes No Yes Yes
Optional temperature sensor ② ② ② ②
Tab.1: SE-i1: Monitoring functions, extent of delivery and options
