4）Fasten the car belt (Figure 19)
●push the baby seat to the car seat.
●pull the lap belt horizontally to
fasten it.
●Pull the upper shoulder belt to
fasten the rest parts and the whole
car belt.
Note：Make sure the baby safety seat is
fixed well.
19
3）Drag the shoulder belt over the
baby seat.put the shoulder belt into
the blue belt route guider (Figure 18
K ).
Note：No twisting or slipping of the car
belts.
2）Pull out the car belt as long as
poosible. Place the lap belt over this
seat and lock the car belt. Then put the
lap belt into the belt route guider
(Figure 17).
Note：No twisting or slipping of the car
belts.
BC100B User Instruction
1514
BIUCO Car Seat
17
18
K
shoulder belt
waist belt
K
5.6 Check the belt and make sure its route
goes on correctly
●Do not place your baby car seat too close to the car seat belt buckles
( Figure 20,21 ).
20 21
