6.4 Installation of canopy and cover
35
Cover installation：
●Put the cover onto the shell. Let the
crotch strap passes through the crotch
pad ( Figure 34 ).
●Let the shoulder straps pass through
corresponding shoulder pad ( Figure
35 ).
●Hold the seat with one hand. Push
the cover into the small gap under
the central adjuster with the other
hand. Then make the cover tidy and
even ( Figure 36 ).
34
36
Press
●Hold the seat back side with one
hand, draw and fix the cover to the
edge of seat ( Figure 37 ).
37
38
●Take similar action from the other
side, and push the bracker pin into
slot to fix the cover ( Figure 38 ).
39
●Set the handle to position A ( Page 8
Figure 1 ), put pins into corresponding
slot on both sides ( Figure 39 ).
BC100B User Instruction
