BIXOLON SPP-R200II Reference Guide

Mobile Printer
Rev. 1.00
- 18 -
5-2-4 lookupDuration
Printer lookup time (unit: second)
@property(readwrite) CGFloat lookupDuration
[Discussion]
It could be a fractional number such as 0.5.
[Availability]
SDK 0.6.0 and later
5-2-5 lookupCount
Number of repeat on signal transmission for printer search
@property(readwrite) unsigned lookupCount
[Discussion]
Default value is set to 1. When it is set to a number bigger than 1, the printer search
signal transmission is repeated by this number at intervals of 0.2 seconds.
[Availability]
SDK 0.6.0 and later
5-2-6 alignment
Horizontal alignment setting
@property(readwrite) int alignment
[Discussion]
Default value is set to left alignment, and this setting affects all output printing including
text and bar code.
[Availability]
SDK 0.8.0 and later
5-2-7 attribute
Text printing property
@property(readwrite) int attribute
[Discussion]
Refer to 2-5 Text Attribute
[Availability]
SDK 0.8.0 and later

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
