BIXOLON SPP-R200II Reference Guide

Mobile Printer
Rev. 1.00
- 14 -
3. BXBarcode Class Reference
Inherits from
NSObject
Confirms to
Framework
BXPrinter.a
[Availability]
iOS 3.1.3 and later
Declared
BXBarcodeInfo.h
3-1 Overview
BXBarcode class is an object that contains information about which barcode types are
supported for each printer to control.
3-2 Properties
3-2-1 barNumber
Barcode Define Number
@property int barNumber
[Discussion]
Printer name is saved automatically by collecting information from the connected printer.
[Availability]
SDK 3.0.3 and later
3-2-2 name
Barcode Name
@property(readwrite) NSString * address
[Discussion]
Printer name is saved automatically by collecting information from the connected printer.
[Availability]
SDK 3.0.3 and later
3-2-3 support
The availability of the barcode.
@property BOOL support
[Discussion]
Printer name is saved automatically by collecting information from the connected printer.
[Availability]
SDK 3.0.3 and later

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
