3-7 Using MSR (Optional, Only SPP-R310)
1) Insert the card as shown in the image
and swipe in the direction of the arrow.
(can be done in both directions)
If the card does not register, first check to see if
it is properly aligned. When swiping the card,
the recommended swiping speed is 100 ~ 1200
mm/sec.
3-8 Recommended Papers
• Receipt paper: PD 160R (Paper Thickness 75μm), New Oji Paper Mfg. Co., Ltd.
• Linerless paper: T6087 (Paper Thickness 76μm), Blumberg GmbH & Co. KG
