6-2 Interface Cable Connection
1) Open the Interface Cap ①.
2) Connect the external communication
cable (optional) ② to the cable
connector of the printer.
Use only the cables (optional) provided by
BIXOLON.
3) Connect the interface cable to the USB
port of the device (PDAs, PCs, etc.).
The interface cable that can be connected with
the printer is available in both USB and Serial
type. Refer to the service manual for detailed
interface cable specifications.
To Next Page
