BIXOLON SRP-270 Command Manual

Rev. 1.01
- 13 -
SRP-270
ESC E n
[Name]
[Format]
[Range]
[Description]
Turn emphasized mode on / off.
ASCII ESC E n
Hex 1B 45 n
Decimal 27 69 n
0 ≤n ≤255 (Only the lowest bit of n is enabled)
Turns emphasized mode on or off.
* When the LSB of n is 0, emphasized mode is turned off.
* When the LSB of n is 1, emphasized mode is turned on.
ESC G n
[Name]
[Format]
[Range]
[Description]
Turn on / off double-strike mode.
ASCII ESC G n
Hex 1B 47 n
Decimal 27 71 n
0 ≤n ≤255
Turns double-strike mode on or off.
* When the LSB of n is 0, double-strike mode is turned off.
* When the LSB of n is 1, double-strike mode is turned on.
ESC J n
[Name]
[Format]
[Range]
[Description]
Print and feed paper.
ASCII ESC G n
Hex 1B 4A n
Decimal 27 74 n
0 ≤n ≤255
Prints the data in the print buffer and feeds the paper n X vertical or
horizontal motion unit.
ESC K n
[Name]
[Format]
[Range]
[Description]
Print and reverse feed.
ASCII ESC K n
Hex 1B 4B n
Decimal 27 75 n
0 ≤n ≤255
Prints the data in the print buffer and feeds the paper n X vertical or
horizontal motion unit in the reverse direction.
ESC R n
[Name]
[Format]
[Range]
[Description]
[Default]
Select an international character set.
ASCII ESC R n
Hex 1B 52 n
Decimal 27 82 n
0 ≤n ≤10
Selects an international character set in from the following table.
n = 0

BIXOLON SRP-270 Specifications

General

Color	No
Maximum print size	-
Media thickness	76 mm
Print technology	Dot matrix
Power requirements	120-230VAC
Standard interfaces	Parallel, Serial
