BIXOLON SRP-270 Command Manual

Rev. 1.01
- 9 -
SRP-270
ESC SP n
[Name]
[Format]
[Range]
[Description]
Set right-side character spacing.
ASCII ESC SP n
Hex 1B 20 n
Decimal 27 32 n
0 ≤n ≤255
Sets the character spacing for the right side of the character to n/160
inches.
ESC ! n
[Name]
[Format]
[Range]
[Description]
Select print mode(s).
ASCII ESC ! n
Hex 1B 21 n
Decimal 27 33 n
0 ≤n ≤255
Selects print mode(s) using n as follows.
Bit Off/On Hex Decimal Function
Off 00 0 Character font(9 ×9) selected. 0
On 01 1 Character font(9 ×7) selected.
1,2 - - - Undefined.
Off 00 0 Emphasized mode not selected. 3
On 08 8 Emphasized mode selected.
Off 00 0 Double-height mode not selected. 4
On 10 16 Double-height mode selected.
Off 00 0 Double-width mode not selected. 5
On 20 32 Double-width mode selected.
6 - - - Undefined.
Off 00 0 Underline mode not selected. 7
On 80 128 Underline mode selected.
* Determine the values of n by adding the value of all the characteristics
you want to select.
ESC % n
[Name]
[Format]
[Range]
[Description]
[Notes]
[Default]
Select / Cancel user-defined character set.
ASCII ESC % n
Hex 1B 25 n
Decimal 27 37 n
0 ≤n ≤255
Selects or cancels the user-defined character set.
When the Least Significant Bit(LSB) is 0, the user-defined character set is
canceled and the internal character set is enabled.
When the LSB is 1, the user-defined character set is selected.
The user-defined character and the downloaded bit image cannot be
defined simultaneously.
n = 0

BIXOLON SRP-270 Specifications

General

Color	No
Maximum print size	-
Media thickness	76 mm
Print technology	Dot matrix
Power requirements	120-230VAC
Standard interfaces	Parallel, Serial
