◈ Product Specifications
Item Description
Printer
Printer type Front output thermal printing
Dot density
SRP-F310: 180 dpi (7dots/mm)
SRP-F312: 203 dpi (8dots/mm)
Printing width
SRP-F310: 72 mm
SRP-F312: 80mm
Number of characters per
line (default value)
SRP-F310: 42 (Font A) / 56 (Font B)
SRP-F312: 48 (Font A) / 64 (Font B)
Printing speed *1)
SRP-F310: 63.82 lines/sec, 270 mm/sec
SRP-F312: 72 lines/sec, 270mm/sec
Receive buffer size 4Kbyte
SMPS input voltage 100~240 VAC
Frequency 50/60 Hz
SMPS output voltage 24 VDC
Temperature
0 ~ 45 ℃ (Operating)
-20 ~ 60 ℃ (Storage)
Humidity
10 ~ 80 % RH (Operating)
10 ~ 90 % RH (Storage)
excluding papers
Auto cutter 1,800,000 cuts
Mechanism MCBF *2) 70,000,000 lines
Paper
Paper type Paper Roll
Paper roll width 79.5±0.5 mm/82.5±0.5 mm
Paper roll diameter Maximum 105mm
Paper thickness 0.062~0.075 mm
Size of paper tube
Inner diameter: Ø12mm (0.47”)
Outer diameter: Ø18mm (0.71”)
※ Note
*1) Printing speed may become slower depending on the baud rate and combination of the
commands.
*2) This value is measured with standard temperature, specified paper, and printing darkness
level 2, and it may change depending on the temperature and printing darkness level.
◈ Automatic Windows Driver Installation for Models with
Serial / Parallel / USB Interface
1. Connect the printer to the computer and turn on the power.
2. Select “Serial/Parallel/USB Auto Search and Configuration” from Port Setting Wizard
Step 1.
3. Click the “Next” button to start searching printers.
* The range of the port searching is as follows.
- Serial: COM1~COM9
- Parallel: LPT1~LPT4
- USB: Plug&play
4. When the port searching is completed, select the corresponding printer in the “Search
Result” and click the “Next” button.
5. Check the selected printer.
You can execute test printing with the “Test Print” button.
6. Click the “Next” button to complete the Windows driver installation with Port Setting
Wizard.
※ Note
When the automatic installation for the selected interface does not work, install the driver
manually from the installation option in Step 2.
- Refer to the User’s Manual for detailed instructions. (Refer to CD)
◈ Windows Driver Installation for Ethernet Interface, Manual
Installation, and Default Value Mode
Refer to the User’s Manual (in CD) for the instructions of other installations besides Serial /
Parallel / USB, including
1. Automatic Ethernet installation
2. Manual installation
3. Default value installation
◈ WEEE (Waste Electrical and Electric Equipment)
This marking shown on the product or its literature, indicates that it should not be disposed
of with other household wastes at the end of its working life. To prevent possible harm to
the environment or people from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the sustainable reuse of
material resources. Household users should contact either the retailer where they purchased
this product, or their local government office, for details of where and how they can take
this item for environmentally safe recycling. Business users should contact their supplier
and check the terms and conditions of the purchase contract. This product should not be
mixed with other commercial wastes for disposal.
☎ BIXOLON Co., Ltd.
● Website http://www.bixolon.com
● Korea Headquarters
(Add) 7~8F, (Sampyeong-dong), 20, Pangyoyeok-ro241beon-gil,
Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400, Korea (ROK)
(Tel.) +82-31-218-5500
● U.S. Office
(Add) BIXOLON America Inc., 3171 Fujita St, Torrance, CA 90505
(Tel.) +1-858 764 4580
● Europe Office
(Add) BIXOLON Europe GmbH, Tiefenbroicher Weg 35 40472 Düsseldorf
(Tel.) +49 (0)211 68 78 54 0
