PIN FUNCTIONS REMARKS
1 Internal DC +5 V Resistor end
2 Voltage Adjust Variable part of resistor
3 Current Adjust Variable part of resistor
4 Ground Resistor end
5 Output OFF Short to Ground
6 N/A
7 N/A
8 N/A
Table 5 – Remote Connector Plug Pin Assignment for Variable Resistors
3. Turn the remote control ON/OFF switch to ON position.
4. Switch on the power supply.
5. Check the output voltage range of the power supply by varying the 5 kΩ
variable resistor for voltage adjustment.
6. Short circuit the main output with 8AWG gauge wire and check the display
for CC setting by varying the 5 kΩ variable resistor for current adjustment.
7. Switch off the power supply.
5.1.3 Enable and Disable the Output
This remote output on/off control can be activated in any of the modes.
By default, Pin 5 is open and output is on.
