7 Specifications
Models 1685B 1687B 1688B
Output
Variable Output Voltage 1 – 60 V 1 – 36 V 1 – 18 V
Variable Output Current 0 – 5 A 0 – 10 A 0 – 20 A
Voltage Regulation
Load (0-100% Load) ≤ 50 mV
Line (90-132 VAC, 170-264
VAC Variation)
≤ 20 mV
Current Regulation
Load (10-90% Rated Voltage) ≤ 100 mA
Line (90-132 VAC, 170-264
VAC Variation)
≤ 50 mA
Ripple & Noise
Ripple & Noise Voltage (rms) ≤ 5 mV
Ripple & Noise Voltage
(peak-peak)
≤ 50 mV
Current Ripple & Noise (rms) ≤ 30 mA
Meter Type & Accuracy
Voltage Meter
3-Digit LED Display ± 0.2% + 3 counts
Current Meter 3-Digit LED Display ± 0.2% + 3 counts
Other
Input Voltage
100-240 VAC 50/60 Hz
Full Load Input Current
3.7 A (100 VAC)
1.7 A (230 VAC)
4.6 A (100 VAC)
2.1 A (230 VAC)
4.6 A (100 VAC)
2.1 A (230 VAC)
Efficiency
82% (100 VAC)
86% (230 VAC)
82% (100 VAC)
86% (230 VAC)
81% (100 VAC)
85% (230 VAC)
Switching Frequency 100 – 120 kHz
